Specs
| Model name | ZD1011-54 |
| Model | Kubota D782-E4-ZD-3 |
| Type | Diesel, liquid-cooled (3cyl.) |
| Displacement | 778.0000 cc / 47.5000 cu. in. |
| Manufacturer | Kubota |
| Safety starting system | Key switch |
| Engine gross power | 14.3900 kW / 19.3000 HP |
| Type | Shaft drive |
| Clutch | Hydraulic independent PTO clutch with wet multi disks |
| PTO brake | Wet single disk |
| Overall length | 2230.0000 mm / 87.8000 in |
| Wheelbase | 1380.0000 mm / 54.3000 in |
| Top of Open Station | 1890.0000 mm / 74.4000 in |
| With mower | 1710.0000 mm / 67.3000 in |
| Without mower | 1210.0000 mm / 47.7000 in |
| With mower | 600.0000 kg / 1323.0000 lb |
| Top of Open Station - folded position | 1430.0000 mm / 56.3000 in |
| Battery | Maintenance free battery : 12 V, CCA : 430A , RC : 80 min |
| Alternator | AC Dynamo: 14 Amps @ 14 Volts |
| Front | 890.0000 mm / 35.0000 in |
| Rear | 930.0000 mm / 36.6000 in |
| System | 2-HST w/ Gear reduction |
| System | 2-hand levers |
| Forward | 14.5000 km/h / 9.0000 mph |
| Reverse | 8.0000 km/h / 5.0000 mph |
| Model | RCK54P-1000Z |
| Type | Kubota ProDeck with ACS |
| Lift system | Hydraulic |
| Mower deck depth | 152.0000 mm / 6.0000 in |
| Belt type | Multi-belt |
| Mower deck thickness | 4.2000 mm / 0.1600 in |
| Type anti-scalp rollers | Rigid |
| Cutting width | 1372.0000 mm / 54.0000 in |
| Number of blades | 3.0000 |
| Cutting height | 127.0000 mm / 5.0000 in |
| Mounting method | Quick joint, parallel linkage |
| Blade tip speed | 5212.0800 m/min / 17100.0000 fpm |
| Seat | Deluxe suspension seat |
| Hour meter | Standard |
| Fuel gauge | Standard |
| Engine stop system | Key stop |
| Water temperature indicator | Standard |
| Fuel tank capacity | 23.0000 l / 6.0000 gal |
| Type | Wet multi disks, foot applied, released |
| Front | 13 × 5.0 - 6 |
| Rear | 24 × 9.5 - 14 |
| Front | Smooth pneumatic |
| Rear | Low profile tire |
