Zero Turn Mower

Z724XKW-3-54

Get A Quote

Features

Transmission with integrated pump and motor

Transmission with integrated pump and motor

The Z700 Series is equipped with dual Parker ® transmissions. Designed for easy maintenance, each transmission has an integrated pump and motor for increased efficiency and simplified service. Also, each transmission has a separate oil supply for increased durability.

Ultimate comfort

Ultimate comfort

The adjustable premium suspension seat is standard on all Z700 models. The 21.2" high back with adjustable armrests, 6" seat slide and 3" vertical travel gives the operator plenty of adjustments that could be made to get the ideal seating position.

Intuitive design

Intuitive design

All controls and indicators are neatly placed for quick, easy, user-friendly access. The EFI models have a dial throttle adjustment that is practically effortless while in the operator seat.

Safe and effective operation controls

Safe and effective operation controls

Wide operator platform with foot activated parking brake and deck lift which helps ensure the operator has full control of the operation levers at all times.

Adjustable controls

Adjustable controls

The operator levers and deck lift pedal, control levers and HST dampeners are adjustable making it comfortable for any one to run the Z700 models

Improved grass catcher design

Improved grass catcher design

This new grass catcher has a new blower guard for added durability and a new latch system to give you better access for routine maintenance and cleaning.

Outstanding stability

Outstanding stability

Z700 series has wide stance rear tires and heavy component positioning under the seat to create a low center of gravity and ultimate terrain hugging performance.

Specs

Model name Z724XKW-2-54
Model Kawasaki ®
Type Gasoline, air-cooled V-Twin
Displacement 726.0000 cc / 44.2000 cu. in.
Manufacturer GH735V
Safety starting system Key switch
Engine gross power 17.5239 kW / 23.5000 HP
Type Belt drive
Clutch Electromagnetic clutch
PTO brake Dry disc
Parking brake Foot pedal
Type Drum disks, foot applied, released
Overall length 2131.0000 mm / 83.9000 in
Wheelbase 1293.0000 mm / 50.9000 in
Top of Open Station 1780.0000 mm / 70.1000 in
With mower 1709.0000 mm / 67.3000 in
Without mower 1280.0000 mm / 50.4000 in
With mower 542.0000 kg / 1195.0000 lb
Top of Open Station - folded position 1235.0000 mm / 48.6000 in
Battery U1 (12V, RC: 45min, CCA: 300, CA: 410)
Generator 15.0000 A / 15.0000 A
Front 954.0000 mm / 37.6000 in
Rear 1021.0000 mm / 40.2000 in
Type Parker® Transmission **** HTG14 Transmissions
System 2 HST-2 G rotor type
System 2 hand levers
Forward 18.0000 km/h / 11.2000 mph
Reverse 9.0000 km/h / 5.6000 mph
Model RCK54P-724Z
Lift system Mechanical
Mower deck depth 152.4000 mm / 6.0000 in
Belt type Single belt
Mower deck thickness 4.1800 mm / 8.0000 in
Type anti-scalp rollers Rigid
Cutting width 1372.0000 mm / 54.0000 in
Number of blades 3.0000
Cutting height 127.0000 mm / 5.0000 in
Mounting method Parallel linkage
Blade tip speed 5669.2800 m/min / 18600.0000 fpm
Seat 21.2" high back seat with "Premium Adjustable Suspension", 3" vertical and 6" front to back travel
Engine stop system Key stop
Fuel tank capacity 43.9000 l / 11.6000 gal
Front 13 × 5.0 – 6
Rear 24 × 9.5 – 12
Front Flat Free
