Wheel Loader

R430

Get A Quote

Features Specs Downloads Get A Quote

Back

Features

Articulation and frame oscillation

Our wheel loaders are most often operated in heavy terrain and we include the features for top performance. Articulation allows the rear tires to follow the same track path as the front tires for greater maneuverability and control of the loader. Rear frame oscillation is intentionally chosen over rear axle oscillation for superior workability in uneven ground conditions.

Hybrid link system

The well balanced cylinder position of the Kubota Z link system combines the advantages of both Z link and parallel link systems. You get strong bucket force when excavating and grading, and a lift path almost parallel to the ground for superior reach and lifting.

Comfortable work station

Comfort is the key to operator efficiency. That’s why the R430 offers a supremely comfortable cab for the operator. From the wide entry and ample leg room to the fully adjustable suspension seat, every detail is designed to reduce stress and fatigue and enhance comfort and operability. The 360° view out the front, sides, and rear lessen the risk of damage in tight work areas, further reducing operator stress. The cab is mounted on rubber pads to minimize sounds and vibrations and maximize ease and comfort. Heat and Air Conditioning are standard on cab models.

Limited slip differential

Limited slip differential Mud, sand, snow, and other challenging terrain are no problem at all for the R430, thanks to its 4-wheel drive and limited slip differential. When one front wheel slips on loose or soft terrain, power is transferred to the opposite wheel, restoring traction to let you power through to firm ground.

Load sensing transmission

As load conditions change, so do the R430’s speed and torque, automatically shifting from high speed/low torque to low speed/high torque. A touch of a button reduces the maximum travel speed while maintaining full auxiliary hydraulic power.

Hydraulic coupler option

Quickly and conveniently exchange attachments to satisfy the needs of any job. You can choose the hydraulic coupler option so you don’t ever have to get out of the cab when changing attachments.

Powerful Kubota engine

The new R430’s powerful engine produces 47.6 horsepower, a remarkable 20% increase over the R420’s 39.2 horsepower. You’ll appreciate that extra muscle when accelerating, pushing, and climbing hills.

Backhoe option

Kubota’s rugged rear backhoe attachment expands the R430’s versatility. With a digging depth of 108.3” (2750 mm), this rear backhoe is ideal for compact trenching tasks.

Specs

Model name	R430
Type	Canopy

Rated engine speed	2600.0000 rpm / 2600.0000 rpm
Engine gross horsepower @ rpm	35.5000 kW / 47.6000 HP
Engine net horsepower @ rpm	33.2000 kW / 44.5000 HP
Displacement	1826.0000 cc / 111.0000 cu. in.
Emission certification	Tier 4
Model name	D1803-CR-TIE4-WL5

Ground clearance	280.0000 mm / 10.8000 in
Overall height	2515.0000 mm / 99.0000 in
Overall length	4355.0000 mm / 172.0000 in
Overall width	1520.0000 mm / 59.0000 in
Weight	3440.0000 kg / 7583.0000 lb

Type	Hydrostatic transmission
Low	4.8000 km/h / 3.0000 mph
High	20.0000 km/h / 12.4000 mph

Fuel tank capacity	54.0000 l / 14.3000 gal
Hydraulic system capacity	58.0000 l / 15.3000 gal
Hydraulic reservoir	42.0000 l / 11.1000 gal

Maximum traction force	24.4000 kgf / 5485.0000 lbf
Tire size	12.5 / 70-16-8PR
Front/Rear axle traction lock	Limited slip differential
Angle of articulation (each way)	40.0000 deg / 40.0000 deg
Angle of rear frame oscillation	8.0000 deg / 8.0000 deg
Loader clearance circle	3695.0000 mm / 145.0000 in
Track circle	3085.0000 mm / 121.0000 in

Auxiliary hydraulic flow	42.1000 l/min / 11.1000 gpm
Auxiliary hydraulic pressure	18.6000 MPa / 2697.0000 psi

Service	Enclosed wet disc
Parking	Spring applied hydraulic released wet disc

With bucket	2420.0000 kg / 5335.0000 lb
With bucket	2085.0000 kg / 4596.0000 lb
With pallet forks	1365.0000 kg / 3009.0000 lb
With bucket	1042.0000 kg / 2298.0000 lb
With pallet forks	682.0000 kg / 1504.0000 lb

Standard bucket capacity	0.3800 m3 / 0.5000 yd3
Breakout force	23.2000 kgf / 5215.0000 lbf
Lifting capacity	16.4000 kgf / 3687.0000 lbf
Raise	4.4000 s / 4.4000 s
Lower	3.3000 s / 3.3000 s
