Utility Tractor

M6-101-1

Get A Quote

Features

New Loader Joystick

New Loader Joystick

Redesigned for maximum comfort, the all new loader joystick fits perfectly in your hand while also being positioned closer to the operator for easier operation. The joystick also features transmission controls for changing the direction of the tractor, as well as the ability to shift up and down through the powershift gears. The operator has full control of the tractor with one hand on the wheel and one on the joystick.

Xpress Restart

Xpress Restart

With the new Xpress Restart, driving has never been easier so beginners can move as quickly as the pros. This feature gives the operator the ability to come to a stop using only the brake, no clutch pedal required.

Stationary PTO

Stationary PTO

Operators can run the rear PTO from both inside or outside the cab. This feature is great for your busy operator using grain augers, feed mixers and more.

Shuttle Shift Modulation

Shuttle Shift Modulation

Enjoy a smoother operation with the ability to adjust the shuttle sensitivity. Adjust the setting based on weight of loads and choose how aggressive the transmission shifts between forward and reverse for maximum efficiency.

Specs

Range gear shift 3-speed mechanical shift with clutch button
Shuttle Microprocessor-controlled electro-hydraulic shuttle
Brake type Hydraulically operated wet disc brakes, with automatic front axle engagement
Forward 24.0000
Reverse 24.0000
Creep (forward) 32.0000
Creep (reverse) 32.0000
Type Intelli-Shift transmission
Bi-speed turn Standard
Creep speed 0.6700 km/h / 0.4200 mph
Main clutch diameter 133.0000 mm / 5.2000 in
Max. traveling speed 35.3000 km/h / 21.9000 mph
Main gear shift 8-speed powershift
Main clutch Multiple wet disc, electro-hydraulically operated
Front wheel drive system Bevel gear type, on-the-go electro-hydraulic engagement, w/ electro-hydraulic front differential loc
Category II
Control system Electronic draft control, lower link sensing, left fender-mounted hitch switch standard
Steering type Hydrostatic power steering
Remote valves 2 standard (3rd, 4th optional) w/ built-in flow control
At 24 in. behind lift point SAE 3100.0000 kg / 6834.0000 lb
At 24 in. behind lift point OECD 2600.0000 kg / 5732.0000 lb
Hitch & remote 70.9000 l/min / 18.7000 gpm
Power steering 60.4000 l/min / 16.0000 gpm
Seat type Swivel, reclining, full adjustment (height, weight, fore & aft.), arm rests, retractable seat belt
Operator area ISO-mounted flat deck, hanging pedals, tilt & telescopic wheel
Lighting 2 headlights, 4 front working lights, 2 rear working lights, 2 tail lights, 4 safety flashers
Standard Heater/Air conditioner, sun visor, front wiper/washer, rear wiper/washer, beverage holder, 12V. 30 A
Crop clearance 450.0000 mm / 17.7000 in
Overall height 2790.0000 mm / 109.8000 in
Overall length 4200.0000 mm / 165.4000 in
Wheelbase 2435.0000 mm / 95.9000 in
Weight 4355.0000 kg / 9601.0000 lb
(min. tread) 2100.0000 mm / 82.7000 in
Front 1580.0000 mm / 62.2000 in
Rear 1520.0000 mm / 59.8000 in
Without brake 4.0000 m / 13.1000 ft
Alternator 130.0000 A / 130.0000 A
Fuel tank capacity 190.0000 l / 50.2000 gal
Displacement 3769.0000 cc / 230.0000 cu. in.
PTO horsepower 61.0000 kW / 82.0000 HP
Engine net horsepower @ rpm 72.4000 kW / 97.1000 HP
Engine gross horsepower @ rpm 77.9000 kW / 104.5000 HP
Rated engine speed 2600.0000 rpm / 2600.0000 rpm
Make Kubota
Exhaust / muffler Under-hood, corner-post exhaust pipe
Cylinders 4.0000
Stroke 120.0000 mm / 4.7200 in
Bore 100.0000 mm / 3.9400 in
Aspiration Turbocharger with intercooler
Air pre-cleaner 8" Dry, dual-element
Type Common Rail System, direct injection, liquid-cooled
Model V3800 – TI – CRS
Battery 100.0000 A / 100.0000 A
DEF tank capacity 16.0000 l / 4.2000 gal
Front 12.4 R24
Rear 18.4 R30
Type Live-independent PTO, hydraulically operated wet clutch, w/ PTO brake
Rated engine speed 540.0000 rpm / 540.0000 rpm
Rated engine speed 1000.0000 rpm / 1000.0000 rpm
Model name M6-101-1
Optional 80" wide axle kit, 3-point high capacity lift cylinders, front weight bumper for 12 weights, front w
