Specs
| Type | E-TVCS, liquid cooled, 3 -cylinder diesel |
| Air pre-cleaner | Dual paper element |
| Bore | 78.0000 mm / 3.1000 in |
| Stroke | 78.4000 mm / 3.1000 in |
| Cooling system | Pressurized radiator |
| Lubrication | Forced lubrication |
| Make | Kubota D1105 |
| Radiator fan | Radial air flow |
| Rated engine speed | 2600.0000 rpm / 2600.0000 rpm |
| Engine gross horsepower @ rpm | 16.3000 kW / 21.9000 HP |
| PTO horsepower | 14.3000 kW / 19.2000 HP |
| Displacement | 1123.0000 cc / 68.5000 cu. in. |
| Fuel tank capacity | 23.0000 l / 6.1000 gal |
| Type | Transmission driven with one way clutch |
| PTO/engine speed | 540.0000 rpm / 540.0000 rpm |
| Clutch | Dry single plate |
| Transmission type | Gear (9 Forward, 3 Reverse) |
| Differential lock | Standard |
| Brake type | Multi-plate wet disc |
| Control system | Position control valve |
| 3-Point hitch | Category I |
| Type | Open center |
| 24" behind lift point | 858.0000 kg / 1290.0000 lb |
| At lift points | 750.0000 kg / 1653.0000 lb |
| Total pump output | 26.4000 l/min / 7.0000 gpm |
| Pump type | Dual pump |
| Hydraulic outlet | Front & Rear outlet |
| Steering type | Integral type power steering |
| Final drive | Spur gear |
| Ground clearance | 300.0000 mm / 11.8000 in |
| Overall height | 1910.0000 mm / 75.2000 in |
| Wheelbase | 1560.0000 mm / 61.4000 in |
| Weight | 605.0000 kg / 1334.0000 lb |
| Without 3 Pt hitch | 2360.0000 mm / 92.9000 in |
| (min. tread) | 900.0000 mm / 35.4000 in |
| Front (Farm) | 44900 |
| Rear (Farm) | 8-16 |
| With brake | 2.1000 m / 6.9000 ft |
| Model name | B2401DTN |
| Cooling system capacity | 3.8000 l / 4.0000 qt |
| Engine lubricant oil capacity | 3.1000 l / 3.3000 qt |
| Transmission oil capacity | 12.5000 l / 3.3000 gal |
| Fuel type | Diesel |
| Forward | 17.5000 km/h / 10.9000 mph |
| Reverse | 9.0000 km/h / 5.6000 mph |
